Hanging Scales Versatile High Capacity Hanging Scales

Starting at $649
Configure and Buy

Overview

The Arlyn Crane Scales are versatile high capacity hanging scales ideal for all lifting, force measurement, and weighing applications. See more product details
Product Code Capacity & Resolution Price
HNG-25 25lb x .005 lb/ 11 kg x 0.002 kg $649
HNG-50 50lb x 0.01 lb / 22 kg x 0.005 kg $649
HNG-100 100lb x 0.02 lb / 45 kg x 0.01 kg $649
HNG-150 150 lb x 0.05 lb / 67 kg x 0.02 kg $649
HNG-200 200 lb x  0.05 lb / 90 kg x 0.02 kg $649
HNG-250 250 lb x 0.05 lb / 113 kg x 0.02 kg $749
HNG-500 500 lb x 0.1 lb / 226 kg x 0.05 kg $949
HNG-750 750 lb x 0.2 lb / 340 kg x 0.1 kg $949
HNG-1000 1000 lb x 0.2 lb / 453 kg x 0.1 kg $949
HNG-1500 1500 lb x 0.5 lb / 680 kg x 0.2 kg $1099
HNG-2000 2000 lb x 0.5 lb / 907 kg x 0.2 kg $1099
HNG-2500 2500 lb x 0.5 lb / 1134 kg x 0.2 kg $1199
HNG-5000 5000 lb x 1 lb / 2260kg x 0.5 kg $1199
HNG-10000 10000 lb x 2 lb/ 4536kg x 1 kg $1499
HNG-20000 20000 lb x 5 lb/ 9072kg x 2 kg  $1699

***CLICK ON THE PRICE TO AUTO-CONFIGURE YOUR SELECTED MODEL***

Details

These adaptable hanging scales are perfect for lifting, force measurement, and hanging weighing tasks. Each scale is equipped with a built-in stainless steel load sensor, protected by a rugged housing. This housing is crafted from bright red polyurethane combined with a special alloy aluminum for enhanced visibility and durability. The digital display features large, 1-inch graphics digits, making weight readings easy to see from afar. Our hanging scales offer impressive accuracy of 0.1% and include digital functions such as pushbutton tare and zero. Additionally, optional swivel shackles and hooks are available to accommodate various hanging needs.

Sensitive but Durable

Designed for durability, the stainless steel load cell allows the scale to endure intensive use while maintaining precise weight measurements. Its robust construction ensures long-term accuracy, even in demanding environments, making it ideal for heavy-duty applications.

Easy to Use

Rather than a basic, confusing numeric display, Arlyn Hanging Scales feature advanced graphic display systems. This allows the scale operator to focus on their tasks without having to troubleshoot the scale’s functionality.

Easy Operation

With a large 1-inch high graphic digital display and a convenient swivel mount, this scale provides pushbutton controls for automatic and keyboard tare functions. It also comes with 450 memory locations, as well as options for zeroing, net/gross weight calculations, and multiple unit conversions, including pounds, kilograms, ounces, and troy units.

Communication Choices

All Arlyn Scales are designed to meet the needs of today’s interconnected industrial environment, offering a broad range of industry-standard communication options, including Ethernet, Wi-Fi, USB, and RS-232.

AxChange Cloud Monitoring

The new AxChange Cloud Monitoring and Weight Tracking system allows you to oversee and manage your industrial scales remotely from any device, anywhere. A limited number of free beta accounts are currently available. Contact us at the factory to discuss your options for hanging scales of lower and higher capacities.

Available Upgrades

Display
Outputs
  • Analog Output 4-20mA (or 0-5VDC)
  • RS-232 Serial Port
  • RS-422/RS-485
  • USB Communication (w/ Virtual Serial Communication)
  • Ethernet TCP/IP Connectivity
  • Wireless TCP/IP Connectivity (UpScale)
Industrial Interfaces (UpScale Display Only)
  • MODBUS RTU/ASCII
  • MODBUS TCP
  • EtherNet/IP Compatibility
  • PROFINET
Printing
  • Label, Paper and Card Printer (RS232)
  • Bluetooth/USB 58mm Thermal Printer (UpScale)
  • Barcode Functions - Printing and Scanning (UpScale)
Setpoint Control
  • Setpoints (Filling Ops, Relay Ctrl, etc)
  • Relays (AC/DC)
  • Alerts (Buzzer Alarm)
  • Light Tower: 2/3 Light Columns
Counting Operation
  • Parts Counting
Data Collection
Extras
  • Flow Rate Function with Alarms (UpScale)
  • Battery Pack
  • NEMA Stainless Steel Enclosure
  • Remote Buttons (ZERO, TARE, PRINT, CYCLE)
  • 24V Power

Specifications

Brochure & Datasheet HNG Series Crane Scales - Specification Sheet (PDF)
MKE-5 Digital Indicator 1" High Graphics LCD digits. Updates between 0.1 to 0.5 sec.
UPSCALE-9 Indicator (Optional) Upgrade to Arlyn UpScale 7" Color LCD Touchscreen. Fully Customizable.
Display Speed Between 0.1 and 0.5 seconds, adjustable
Overload Condition Display warning message at 102% of scale capacity
Current Consumption Approx. 0.1A
Power Requirements 117/220 VAC, 50/60 Hz. Optional 24VDC Available.
Operating Temperature 14°F to 104°F
Accuracy 0.1% of full scale.
Multiple Units Weighs in Lbs, Kilos, Grams, Ounces, etc.
Eliminates Maintenance No internal moving parts
Easy Operation Pushbuttons functions for automatic, keyboard tare, zero functions with memory, net/gross
Minimum Sampling Rate 10 Hz
